| Model | D-900 |
|---|---|
| Irrigation pump | 1hp agricultural pump (Wilo pump : PUN-950), |
| Control of nutrient solution |
Venturi injection type (30∼300L/hour) |
| Method of control |
Microprocessor (automatic control depending on the |
| Size | (L)90cm x (W)60cm x (H)106cm |
| Weight | 50Kg |
| Power source | Single-phase, AC220V |
- * Capacity of irrigation pump is subject to change depending on the orderer demand.
- * Product is subject to change without prior notice to improve its quality or capacity.
Features of D-900 system
| Item | Content | Others |
|---|---|---|
| Method of control |
•Time control : Irrigation works up to max. 24 times at the setting time •Interval control : Irrigation works depending on start/finish time/interval (minutes, seconds(max. 99 times) •External control : Irrigation works depending on the external signal (moisture sensor, etc)/start time/finish time |
|
| Irrigation method |
•Irrigation by time : Irrigation works depending on the setting of time unit, "minute/second," per sector | |
| Irrigation sector |
•To be irrigated up to 10 sectors | ※ EC(option) |
| Nutrient solution |
•Basic : liquid fertilizer, option : EC control (A + B solution) | |
| Features of the program |
•Control of liquid fertilizer : Setting & control of the amount of liquid fertilizer in percentage •Frost control : Frost control function depending on the temperature set value (option) •Irrigation setting : Setting for EC/amount of irrigation per sector •Time control : Setting of nutrient solution to be used for each irrigation time •Irrigation report : Saving the number of irrigation for 7 days •Warning of nutrient solution : EC value gives warning signal & shutdown of the system(EC option) •Output test : Output test for the system can be performed •1 time irrigation :1 time irrigation works by one-touch button other than time setting •Pause : One-touch emergency shutoff function •Error display : Message & corrective action for error is displayed |
※EC(option) ※Frost control (AC24V) Anti-frost fan & sprinkler Additional installation is required |
| Features of the program |
•Nutrient solution control valve on the front : Current value of nutrient solution
can be controlled •Installation space can be minimized due to the solution control valve on the front •Anti-lightening circuit, components are built in •Big size of Korean LCD(Korean character 20x4) with bring screen •PE pipe : Durable & chemical-resistant valves/pipes were used •Switch box : Corrosion-resistant stainless steel was used •Main structure : Main body is made with 40mm x 40mm strong aluminum profile |
