| Specification of the system |
EC | Sensor | 4-pole sensor |
|---|---|---|---|
| Measuring range |
4 ~ 20mA (0.0 ~ 19.9 Sm/cm) | ||
| Temperature to be used |
0.0℃ ~ 80℃ | ||
| Material | Case(PVC), electrode(SUS 316) | ||
| TYPE | Screw (attachable type) | ||
| pH | Sensor | Combined glass electrode |
|
| Measuring range |
4 ~ 20mA(0.0 ~ 13.9 pH | ||
| Temperature to be used |
0.0℃ ~ 45℃ | ||
| Monitor | Mono LCD | 128 pixels * 64 pixels |
특징
- - Always monitoring EC/pH values
- - Always check out concentration of nutrient/substrate solution and adjust its value without delay
- - 1 output under the setting value of EC (mixing for nutrient solution can be usable)
- - 1 output under the setting value of pH (mixing for nutrient solution can be usable)
- - It can be connected to PC and keep the data stored (option)
- - As a detachable type, it can be moved if necessary
